Victron Energy - Battery charger Blue Smart IP22 24V/16A, 3 outputs
  • 261,00 €
  • 183,78 €
Lowest price at PriceRunner

Blue Smart IP22 battery charger 24V/16A 3 outputs BT from Victron Energy. Professional charger for boats and vehicles with the VictronConnect app.

Share
Article number: BPC241648002
EAN: 8719076052517
Manufacturer: Victron Energy

Victron Energy Blue Smart IP22 24V/16A is a battery charger for 24V systems with 3 outputs and built-in Bluetooth. Charging is set up and monitored in the VictronConnect app, and the charger is suitable for both lead-acid and lithium batteries (LiFePO4) on board, in the motorhome and in the workshop. The three isolated outputs charge three battery banks simultaneously.

Features

  • Built-in Bluetooth for setup and monitoring in VictronConnect
  • Adaptive 6-stage charging, with a dedicated mode for lithium batteries
  • Storage mode with reduced voltage minimises gassing and corrosion
  • Recharges batteries that are discharged all the way to 0V
  • NIGHT and LOW modes halve the current for quiet operation
  • Can receive voltage and temperature data from Smart Battery Sense, BMV-712 or SmartShunt
  • Three isolated outputs for three battery banks

Technical specifications

  • System voltage: 24V
  • Charge current: 16A (8A in NIGHT/LOW)
  • Outputs: 3
  • Mains voltage: 180-265V AC, 45-65 Hz
  • Charge curve: Adaptive, 6-stage
  • Absorption voltage: 28.8V (normal), 29.4V (high), 28.4V (Li-ion)
  • Float voltage: 27.6V (normal and high), 27.0V (Li-ion)
  • Storage voltage: 26.4V
  • Battery types: Lead-acid (flooded, AGM, GEL) and lithium (LiFePO4)
  • Efficiency: 94 %
  • No-load consumption: 0.5W
  • Communication: Bluetooth
  • Protection rating: IP22
  • Operating temperature: -40 to +60 °C (full power up to 40 °C)
  • Approvals: EN 60335-1, EN 60335-2-29, ECE R10-5

In the box

  • 1 x Battery charger with mains cable and battery cables

Compatibility

  • Smart Battery Sense, BMV-712 and SmartShunt via VE.Smart Networking (voltage and temperature)

Video

History and settings for Blue Smart chargers in VictronConnect

Using a Blue Smart charger as a power supply
