Maretron - Terminator Micro female, NMEA 2000
  • 19,80 €
  • 19,35 €
Lowest price at PriceRunner

Maretron TR-CF is a specially designed Micro female terminator for NMEA 2000 networks. It terminates the cable bus for correct signalling in marine electronics.

Share
Article number: TR-CF
EAN: 873804001432
Manufacturer: Maretron

Maretron terminator Micro female is a termination component for NMEA 2000 networks. The unit connects at one end of an NMEA 2000 cable bus to prevent signal reflections and ensure correct data communication in marine electronics systems. It is specially designed with a special connector for installations where a standard Micro female termination is required.

Features

  • Used for terminating the signal bus in an NMEA 2000 network
  • Fitted with a special Micro female connector
  • Prevents signal reflections and reduces interference in data communication
  • Designed for marine environments and powered networks

Technical specifications

  • Type: Terminator, Micro female
  • Resistance: 120 Ω, 0.5W
  • Rated voltage: 10-30V DC
  • Material: PUR, gold-plated contacts, nickel-plated nut
  • Water resistance: IP68
  • Approvals: NMEA 2000, IEC 61162-3

Compatibility

  • NMEA 2000 networks and standard Micro cables
